IP65 Waterproof LED Down Light

  • Feature


  • IP65 waterproof, suitable for outdoor, public bathhouse and bathroom.

    Super quality Citizen COB LED source, high lumen, uniform light

    Die-casting aluminum lamp housing, excellent heat dissipation
  • Gold / white / black reflector can be selected
  • CRI >90Ra, highly restore original color

  • High luminous efficiency 110-120lm/w

  • Simple and fashionable appearance, meet the aesthetic requirements

  • Long lifespan, 5 years warranty

      Multiple brands LED driver can be selected, no flicker


  • Parameters

    Input VoltageAC220-240V
    Color Temperature2700K, 3000K, 4000K, 5000K, 6000K optional
    Lighting Efficiency1000-1100 LM/W
    Anti-GlareUGR <17
    CRI80Ra  / 90Ra / 97Ra
    Power Factor>0.95
    Lifetime50,000H
    Waterproof LevelIP44
    DimmableN / Triac Dim / 0-10V Dim
    InstallationRecessed
    AdjustableFixed
    Housing MaterialsDie-casting aluminum alloy



    Specification

    Item                  Power    Luminous Flux
    (lm)
    Dimension
    (mm)
    Cut-out
    (mm)
    Beam Angle
    DS-CL-18W-IP6515W1800lmD100*H649015°24°38°60°
    DS-CL-28W-IP6525W2800lmD136*H8312515°24°38°60°
    DS-CL-38W-IP6535W3800lmD158*H9614515°24°38°60°
    DS-CL-48W-IP6548W4800lm
    D180*H10916515°24°38°60°
    DS-CL-18W-IP65S18W1800lm100*100*H6490*9015°24°38°60°
    DS-CL-28W-IP65S28W2800lm136*136*H83125*12515°24°38°60°
    DS-CL-38W-IP65S38W3800lm158*158*H96145*14515°24°38°60°
    DS-CL-48W-IP65S48W4800lm
    180*180*H100165*16515°24°38°60°
