- Powergear 3 phase (4 wire, 6 wire)
- Ultra low glare UGR (Lens 8-12, reflector 15-19), more eye protection
- Up to CRI 97Ra, highly restore original color
- Kinds of beam angles are available
- Up to 130lm/w lighting efficiency, more energy saving
- Simple and fashionable appearance, meet the aesthetic requirements
- Long lifespan, 5 years warranty
- Multiple brands LED driver can be selected, no flicker
Parameters
| Input Voltage | 200-240V |
| Color Temperature | 2700K, 3000K, 4000K, 5000K, 6000K optional |
| Beam Angle (lens) | 15° 24° 36° 60° |
| Beam Angle (Reflector) | 30° 40° 60° |
| Lighting Efficiency | Up to 130 LM/W |
| Anti-Glare | UGR Lens 8-12, Reflector 15-19 |
| CRI | 80Ra / 90Ra / 97Ra |
| Power Factor | >0.9 |
| Lifetime | 50,000H |
| Dimmable | N / 0-10V / Triac Dim / Dali / 2.4G Controller / Optional |
| Adapter | 3 phase (4 wire, 6 wire) |
Specification
| Item | Power |
LuminousFlux (lm) |
LED+Radiator (mm) |
Whole Lamp Size(mm) | LED Current |
| DS-RL12W- COB- 4 | 12W | 1400-1600 | Φ75*L90 | L190*W124 | 36v DC 500mA |
| DS-RL20W-COB-4 | 20W | 2300-2400 | Φ75*L90 | L190*W125 | 36v DC 500mA |
| DS-RL30W-COB-4 | 30W | 3400-3700 | Φ100*L98 | L223*W160 | 36v DC 800mA |
| DS-RL40W-COB-4 | 40W | 4500-4800 | Φ100*L98 | L223*W160 | 36v DC 1050mA |
| DS-RL50W-COB-4 | 50W | 5700-6000 | Φ100*L118 | L223*W160 | 36v DC 1300mA |
| DS-RL60W-COB-4 | 60W | 6500-7000 | Φ125*L120 | L248*W185 | 36v DC 1650mA |
