- Global / Powergear 3 phase 4 wire / 6 wire
- 6063 brused aluminum alloy,better for heat dissipation
- 350degree adjustable horizontaly, 90degree adjustable vertical
- Famous LED brand, LM80,such as Citizen, CREE, Epistar, Samsung,Osram, LED chip lumen is 160lm/w
- Ultra low glare UGR 14-19, more eye protection
- Up to CRI 97Ra, highly restore original color
- Up to 130lm/w lighting efficiency, more energy saving
- Simple and fashionable appearance, meet the aesthetic requirements
- Long lifespan, 5 years warranty
- Multiple brands LED driver can be selected, Osram / Tridonic / Philips / HEP / Boke
- No flicher
Parameters
| Input Voltage | 200-240V |
| Color Temperature | 2700K, 3000K, 4000K, 5000K, 6000K optional |
| Housing Color | White / Black / Silver |
| Beam Angle (lens) | 10° 20° 30° 60° |
| Beam Angle (Reflector) | 12° 23° 36° 60° |
| Lighting Efficiency | Up to 130 LM/W |
| SDCM | <3 |
| Anti-Glare | UGR Lens 8-12, Reflector 15-19 |
| CRI | 80Ra / 90Ra / 97Ra |
| Power Factor | >0.95 |
| THD | <15 |
| Lifetime | 50,000H |
| Dimmable | N / 0-10V / Triac Dim / Dali / 2.4G Controller / Optional |
| Adapter | Global / Powergear 3 phase 4 wire |
Specification
| Item | Power | Luminous Flux (lm) | Size(mm) |
| DS-RL15W-COB-8L | 15W | 1700-1800 | Φ90*L190*188 |
| DS-RL25W-COB-8L | 25w | 2800-3000 | Φ90*L190*188 |
| DS-RL30W-COB-8L | 30W | 3300-3600 | Φ90*L190*188 |
| DS-RL35W-COB-8L | 35W | 3900-4200 | Φ90*L190*188 |
